Peripheral

• Accessory Port

• RSA/NATO Ports
  1/4"-20 Mounting Hole
  Cold Shoe
  Video Transmission/LiDAR Range Finder Port (USB-C)
  RSS Camera Control Port (USB-C)
  Focus Motor Port (USB-C)

• Battery

• Model: BG30-1950 mAh-15.4V
  Type: LiPo 4S
  Capacity: 1950 mAh
  Energy: 30 Wh
  Max. Runtime: 12 hours ^[1]
  Charging Time: Approx. 1.5 hours (using 24W charger; it is recommended to use QC 2.0 or PD protocol chargers)
  Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

• Connections

• Bluetooth 5.0
  Charging Port (USB-C)

• Ronin App Requirements

• iOS 11.0 or above
  Android 7.0 or above

• Languages Supported by the Touchscreen

• English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai

Working Performance

• Tested Payload

• 4.5 kg (10 lbs)

• Maximum Controlled Rotation Speed

• Pan: 360°/s
  Tilt: 360°/s
  Roll: 360°/s

• Mechanical Range

• Pan axis: 360° continuous rotation
  Roll axis: -95° to +240°
  Tilt axis: -112° to +214°

Mechanical & Electrical Characteristics

• Operating Frequency

• 2.400-2.484 GHz

• Bluetooth Transmitter Power

• <8 dBm

• Operating Temperature

• -20° to 45° C (-4° to 113° F)

• Weight

• Gimbal: Approx. 1,143 g (2.51 lbs)
  Grip: Approx. 265 g (0.58 lbs)
  Extended Grip/Tripod (Metal): Approx. 226 g (0.49 lbs)
  Upper and Lower Quick-Release Plates: Approx. 107 g (0.23 lbs)

• Gimbal Dimensions

• Folded: 268×276×68 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod)
  Unfolded: 415×218×195 mm (L×W×H, height includes grip and excludes the Extended Grip/Tripod)

DJI Ronin Image Transmitter

• Connections

• Power/Communication Port (USB-C)
  HDMI Port (Mini HDMI)
  RSS Camera Control Port (USB-C)

• Expansion Port

• Cold Shoe

• Operating Frequency

• 2.400-2.484 GHz
  5.725-5.850 GHz

• Weight

• 126 g (0.27 lbs)

• Dimensions

• Length: 82×63×24 mm (L×W×H)

• Transmitter Power (EIRP)

• 2.400-2.484 GHz:
  <25 dBm (FCC)
  <20 dBm (CE/SRRC/MIC)5.725-5.850 GHz:
  <25 dBm (FCC/SRRC)
  <14 dBm (CE)

• Battery

• Capacity: 2970 mAh
  Compatible Charger: 5 V/2 A
  Charging Time: Approx. 2.5 hours
  Operating Time: Approx. 3.5 hours

• Transmission Range

• 200 m (SRRC/FCC) ^[2]
  100 m (CE) ^[2]

• Latency

• 60 ms

• Operating Current/Voltage

• 900 mA/3.7 V

• Operating Temperature

• 0° to 45° C (32° to 113° F)

DJI LiDAR Range Finder (RS)

• Accessory Port

• Cold Shoe
  1/4"-20 Mounting Hole
  USB-C Port
  USB-C Power/CVBS/CAN Data Port

• Image Sensor

• Resolution: 448×298 on the RS touchscreen
  FOV: 57.4° (horizontal), 44.6° (vertical), 70.1° (diagonal)
  Frame Rate: 30fps
  Focal Length: 30mm Equivalent

• ToF Sensor

• Resolution: 240×180
  Sensing Range: 0.5 to 14 m ^[3]
  FOV: 57.4° (horizontal), 44.6° (vertical), 70.1° (diagonal)
  Frequency: 25 Hz
  Focal Length: 30mm equivalent
  Distance Error: 1%

• Machine Learning

• Frequency: 30 Hz
  Tracking Subjects: Can recognize up to five subjects at the same time, and choose one to follow
  Smart Object Identification: Human face, head, and body

• Electrical Properties

• Power Consumption: 6.8 W
  Input: 7 to 16 V

• Operating Temperature

• -20° to 45° C (-4° to 113° F)

• Mechanical Properties

• Dimensions: 66×57×24 mm (L×W×H)
  Weight: Approx. 130 g (0.28 lbs)
  Mounting Plate Height: 30 mm

• Lenses that Do Not Need Calibration

• DZOFILM Vespid Cyber 35 mm
  DZOFILM Vespid Cyber 50 mm
  DZOFILM Vespid Cyber 75 mm

Notes

• 1. Measured with the equipment in a level and stationary state, the gimbal balanced, three axes in an active state, and the battery only powering the gimbal.
  2. In open environments free of obstructions or interference.
  3. In environments with a brightness level of 80,000 lux or below.
