AC (GRID-TIED)

• Rated Output Power:6000W
• Output Apparent Power:6000VA
• Wiring: L1/L2/L3/N/PE
• Rated Voltage: 230V/400V
• Voltage Range: 185V-285VAC×3
• Rated Output Current: 8.7A×3
• Maximum Output Current: 9.1A×3
• Input Frequency: 50Hz
• Frequency Range: 47.5-51.5Hz
• Maximum Output Apparent Power: 12000VA, Bypass + Charge
• Maximum Input Current: 18A, Bypass + Charge
• Power Factor (PF) : 0.9 Leading-0.9 Lagging Adjustable
• Current Total Harmonic Distortion (THD) : ＜3%, At Rated Power
• On and Off-Grid Switching Time : ＜10ms
• Round-trip Efficiency : >82%(AC/AC), Grid-Battery-AC Load
• Protection : Anti-islanding Protection, Residual Current Monitor
Output Overcurrent Protection
AC (OFF-GRID)
• Rated Output Power : 6000VA
•  Output Voltage: 230V/400V
• Output Current : 8.7A×3
• Output Frequency: 50Hz
• Inversion Efficiency : 94.0% Max.
• Output Voltage THD : ＜3%, Purely Resistive Load
• Protection: Output Overcurrent Protection
Output Short-circuit Protection
Over Temperature Protection
PV INPUT
• Maximum Input Power : 6000W
• MPPT Channel : 2
• Array In Series : 1
• Maximum Input Voltage : 550V
• MPPT Voltage Range/Rated : 150V-500V/360V
• Single MPPT Maximum Input Current : 12.5A
• Single MPPT Maximum Short-circuit Current : 15A
• MPPT Efficiency : 99.9%
• PV Inverter Efficiency : 93.6% Peak
• Protection: Reverse Polarity Protection
Insulation Resistance Detection
GENERAL
• Relative Humidity : 5%-95%
• Static Power :23W
• Standby Power: 64W
• Operating Temperature : -20℃-50℃
•Noise: ≤50dB (A)
• Cooling: Forced Air Cooling
• Protection Grade: IP65
• Operating Altitude: ≤2000m
•Dimensions (L*W*H): 636mm×325mm×370mm
• משקל: 40 ק"ג
